| Características Inteligentes |
| Activador De Alarma |
Motion detection, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
| Cámara |
| Sensor De Imagen |
1/2.7" Progressive Scan CMOS |
| Iluminación Mínima |
Color: 0.028 Lux @ (F2.0, AGC ON) |
| Velocidad De Obturación |
1/3 s to 1/100,000 s |
| Obturador Lento |
Yes |
| Ajuste De Ángulo |
Pan: 0° to 360°, tilt: -90° to 90°, rotate: 0° to 90° |
| WDR |
DWDR |
| Día Y Noche |
IR Cut Filter |
| Lente |
| Apertura |
F2.0 |
|
| Enfoque |
Fixed |
|
| FOV |
2.8 mm, horizontal FOV: 114.5°, vertical FOV: 62°, diagonal FOV: 135.5° |
| 4 mm, horizontal FOV: 86°, vertical FOV: 46.5°, diagonal FOV: 102.5° |
| Montura Del Lente |
M12 |
| Longitud Focal |
2.8/4 mm |
| Red |
| Almacenamiento En Red |
Support micro SD/SDHC/SDXC card (max. 256 GB), local storage and NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
| Activador De Alarma |
Motion detection, illegal login |
| Protocolos |
TCP/IP, ICMP, DHCP, DNS, DDNS, HTTP, RTP, RTSP, NTP, UPnP, IGMP, IPv6, UDP, QoS, Bonjour |
| API |
ISAPI |
| Vista En Vivo Simultánea |
Up to 6 channels |
| Usuario/Operador |
Up to 32 users |
| 3 levels: Administrator, Operator and User |
| Cliente |
Wired network: Hik-Connect, iVMS-4200 |
| Wi-Fi: iVMS-4200 |
| *Wi-Fi connection with Hik-Connect directly is not possible. |
| Navegador Web |
Plug-in required live view: IE8, IE9, IE10, IE11 |
| Local service: Chrome 57.0+, Firefox 52.0+ |
| Función General |
Anti-flicker, heartbeat, mirror, password protection, password reset via e-mail |
| Versión De Firmware |
V5.5.101 |
| Vídeo |
| Max. Resolución |
1920 × 1080 |
| Audio |
| Filtro De Ruido Ambiental |
Yes |
| Frecuencia De Muestreo De Audio |
8 kHz/16 kHz |
| Interfaz |
| Botón De Reinicio |
Yes |
| On-Board Storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
| Interfaz De Comunicación |
1 RJ45 10M/100M self-adaptive Ethernet port |
| Audio |
1 Built-in mic, mono sound |
| Imagen |
| Max. Resolución |
1920 × 1080 |
| Main Stream |
50Hz: 25 fps (1920 × 1080, 1280 × 720) |
| 60Hz: 30 fps (1920 × 1080, 1280 × 720) |
| Sub-Stream |
50Hz: 25 fps (640 × 360) |
| 60Hz: 30 fps (640 × 360) |
| Mejora De La Imagen |
BLC, HLC, 3D DNR |
| Interruptor Día/Noche |
Day, night, auto, scheduled |
| Configuración De Imagen |
Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
| General |
| Condiciones De Operación |
-30 °C to +60 °C (-22°F to +140 °F), humidity 95% or less (non-condensing) |
| Fuente De Alimentación |
12 VDC ± 25%, Ø5.5 mm coaxial power plug |
| Power Consumption And Current |
12 VDC, 0.4 A, max. 5 W |
| Material |
Front cover: metal, back cover: plastic |
| Dimensiones |
Camera: 177.6 mm × 67.8 mm × 66.2 mm (7" × 2.7\" × 2.6\") |
| With package: 264 mm × 129 mm × 120 mm (10.4 × 5.1\" × 4.7\")" |
| Camera: approx. 270 g (0.6 lb.) |
| With package: approx. 470 g (1 lb.) |
| Certificaciones |
| Protección |
Ingress protection: IP66 (IEC 60529-2013) |
| Compresión Estándar |
| Compresión De Vídeo |
Main stream: H.265+/H.265/H.264+/H.264 |
| Sub-stream: H.265/H.264 |
| H.264 + |
Main stream supports |
| H.265 + |
Main stream supports |
| Tipo H.264 |
Baseline Profile/Main Profile |
| Tipo H.265 |
Baseline Profile |
| Vídeo Bitrate |
32 Kbps to 8 Mbps |
| Compresión De Audio |
G.711/G.722.1/G.726/MP2L2/PCM |
| Velocidad De Bits De Audio |
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32 to 160Kbps(MP2L2) |
| IR |
|
| Rango IR |
Up to 30 m |
| Longitud De Onda |
850 nm |
| Wi-Fi (-W) |
| Wireless Standards |
IEEE 802.11b/g/n |
| Rango De Frecuencia |
2.4 GHz to 2.4835 GHz |
| Tasas De Transferencia |
11b: 11 Mbps |
| 11g: 54 Mbps |
| 11n: up to 150 Mbps |
| Seguridad |
64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
| Channel Bandwidth |
20 MHz/40 MHz |
| Alcance Inalámbrico |
Up to 80 m (The performance varies based on actual environment.) |
| Protocolos |
802.11b: CCK, DQPSK, DBPSK |
| 802.11g/n: 64-QAM, 16-QAM, QPSK, BPSK |
